10oz for Internal and External layers#Four layers heavy copper thickness #FR4 Printed Circuit Board.#Multilayer PCB

1.Detailed Specification of PCB

2.Information of Company

Shenzhen KAZ Circuit is a manufacturer of PCB and PCBA. Certificates: ISO 9001, UL (E337072), TS16949 (0259279), RoHS We have over 300 employees and 8,000 square meters building area. Our products include Normal Tg FR4, High Tg FR4, PTFE, Rogers, Low Dk/Df, FPC, Rigid-Flex PCB and Aluminum, Copper base PCB, etc. Assembly service including SMT, DIP with six assembly lines. --Providing one stop service for our clients including: -PCB Production (prototype, small & medium production, mass production) -Components Sourcing -PCB Assembly (SMT, SMD, DIP) Our PCB technology capacity includes 1 to 50 layers, minimum dill hole size of 0.1mm, minimum track/line size of 0.075mm, surface treatment of OSP, HAL, HASL, ENIG, Gold Finger and more. We can make our production capacity of 12,000 square meters/month for double sides and 8,000 square meters/month for multilayer.

3.Pictures of PCB

In the year of 2024, SHENZHEN KAIZUO ELECTRONIC TECHNOLOGY CO., LTD (KAZ CIRCUIT) has joined Kingsum group (www.kingsumpcba.com), to seek for a larger market share from PCB manufacturing, component sourcing, pcb assembly, and box build assembly with better price and lead time.

Founded in 2007, KaiZuo Electronic (hereinafter referred to as KAZ) is a professional & high quality provider of Electronic Manufacturer Service (EMS) from China. With about 300 experienced employees, KAZ can provide customers with one stop services including PCB manufacturing, Components Sourcing, PCB Assembly, Cable Assembly, Box Building, IC Programming, Functional and Aging Testing. Certified with ISO9001, UL, RoHS, TS16949.

Equipped with 5 high-speed SMT, automatic printing machine (DSP1008), MIRAE MX200/MIRAE MX400 high-speed production line, YAMAHA equipment (YS24/YG12F...), reflow soldering (NS-1000), AOI testing equipment (JTA-320-M), X-Ray inspection equipment (Nikon AX7200), 2 DIP production lines and Nitto wave soldering.

After focusing on the electronic manufacturer services for 13+ years, KAZ has established long-term cooperated & satisfied customers all over the world. Mainly from North America, European, Asia and Australia. Application fields including industrial control, IT/Networking, IoT, security, automotive, power electronics, consumer electronics, lighting, etc.

Some of KAZ Customers:

Certificates including:

• ISO9001
• TS16949
• UL
• RoHS
